FA and Machine vision lenses



12mm 5MP Manual

12mm  5MP  Manual
  • 10MP
  • 2/3"
PDF Download
FA-M12(5MP)-23F21
Resolution 5 Megapixel
Image format 2/3"
Focal length 12mm
Aperture F2.1
Mount C
Field Angle
D×H×V(°)
°" 2/3 1/2
D 48.9 36.8
H 40.1 29.8
V 30.7 22.6
Optical Distortion 0.1m -0.98% -0.66%
0.4m 0.15% -0.11%
+∞ 0.65% 0.13%
CRA ≤8.03°
M.O.D. 0.1m
Dimension Φ40×43.3mm
Weight 97±2g
Flange BFL 17.526mm
BFL in air 12.56mm
MBF in air 12.09mm
IR Correction /
Operation Iris Manual
Focus Manual
Zoom /
Operating temperature -10℃~+50℃

25mm 10MP Manual

25mm  10MP  Manual
  • 10MP
  • 1"
PDF Download

FA-M25(10MP)-1F21
Resolution 10 Megapixel
Image format 1"
Focal length 25mm
Aperture F2.1
Mount C
Field Angle
D×H×V(°)
°" 1 2/3
D 35.3 24.7
H 28.6 19.9
V 21.7 15

Optical Distortion
0.15m -0.29% -0.21%
0.5m 0.06% -0.05%
+∞ 0.35% 0.08%
CRA ≤9.56°
M.O.D. 0.15m
Dimension Φ45×65.1~76.2mm
Weight 201±5g
Flange BFL 17.526mm
BFL in air 12.09mm
MBF in air 11.49mm
IR Correction /
Operation Iris Manual
Focus Manual
Zoom /
Operating temperature -10℃~+50℃
